ESCO® Ultralok® U30 Excavator Tooth – U30CHB (Chisel Heavy Back)
Product number:
U30CHB
€113.50
incl. VAT €135.07
Product information
The ESCO® Ultralok® U30CHB is a wear part for the Ultralok® tooth system in size U30. The C – Chisel profile is designed for directed penetration and controlled material breaking applications.
The HB – Heavy Back version indicates a reinforced rear section of the tooth body. The tooth fits form-locking into the tooth pocket at the adapter interface and forms part of the Ground Engaging Tools (GET). Tooth replacement within the Ultralok® tooth system is hammerless via the integrated locking mechanism.
Technical Data:
- System: ESCO® Ultralok®
- System Size: U30
- Part Number: U30CHB
- Tooth Profile: C – Chisel
- Version: HB – Heavy Back
- Dimension A – Overall length: 259 mm
- Dimension B – Tip width: 36 mm
- Dimension C – Tip height / thickness: 9 mm
- Dimension D – Base width / pocket width: 105 mm
- Weight: 5 kg
| Tooth Size: | U30 |
|---|---|
| Shipping Weight: | 4.67 kg |
