LIS® Hydraulic Hammer for Excavators 50 - 65 t | Without mounting

The LIS® LIS195A-BT-WOP hydraulic breaker (box-type) is optimized for excavators in the 50 to 65 tonne class. Equipped with a nitrogen-assisted impact mechanism and manufactured according to the highest LIS® Germany quality standards, this heavy-duty demolition breaker delivers maximum performance in severe concrete demolition, quarry operations and demanding civil engineering projects. Supplied without mounting bracket, it can be flexibly adapted to various common quick coupler systems. Includes 12 months or 1,500 operating hours warranty.

Main Features and Advantages

Optimized performance: Nitrogen-assisted impact energy for maximum efficiency.
Compatible: 50–65 t excavators

Technical Specifications

• Suitable for excavator class: approx. 50–65 t
• Mounting / Suitable for quick coupler: Without mounting bracket
• Weight: 4,900 kg
• Length: approx. 3,895 mm
• Width: approx. 520 mm
• Oil flow (min–max): 260–340 l/min
• Operating pressure: 260–380 bar
• Impact rate: 100–150 bpm
• Chisel diameter: 195 mm
• Impact energy: Not specified

Scope of delivery: 2x chisels + 2x hydraulic hoses + 1x seal kit + without mounting bracket + tool kit + 2x grease cartridges + operating manual
