Heavy Duty long bucket tooth suitable for CAT® J300 | Ref. 9N-4302 | LIS®
Product number:
9N4302SX
€23.54
incl. VAT €28.01
Product information
The LIS® Heavy Duty long tooth tip is a bucket tooth suitable for the CAT® J300 tooth system. This replaceable wear part is used on compatible tooth interfaces and is designed for abrasive and high-load digging and loading conditions.
For technical identification, the reference numbers 9N-4302 and 4T-2303, the Heavy Duty Long design, the existing tooth interface and the retention configuration must be checked.
Technical Data
- Compatible system: CAT® J-System J300
- Product type: tooth tip / bucket tooth
- Reference numbers: 9N-4302, 4T-2303 (also 9N4302, 4T2303)
- Length approx.: 222 mm
- Height approx.: 104 mm
- Cutting edge width approx.: 71.50 mm
- Adapter end width approx.: 90 mm
- Design: Heavy Duty Long
- Material: high wear-resistant cast steel
- Application profile: abrasive and high-load digging and loading conditions
| Tooth Size: | J300 |
|---|---|
| Shipping Weight: | 5.7 kg |
