ESCO® Ultralok® U45 Left Corner Point for Continuous Edge – U45LCE (Continuous Edge Left Corner)

The ESCO® Ultralok® U45LCE is a continuous edge corner point for the U45 Ultralok® tooth system. The profile is Corner Point for Continuous Edge and the installation position is left. As a wear part, the point is seated with a form-fit connection in the tooth pocket at the adapter interface.

The continuous-edge configuration is designed for cutting edge layouts with overlapping point segments and forms a substantially closed working edge for grading, clean-up and profiling work. Point replacement uses the integrated Ultralok® locking system.

Technical Data

• System: ESCO® Ultralok®
• System Size: U45
• Part Number: U45LCE
• Product Type: Continuous Edge Corner Point
• Position Code: LCE
• Tooth Profile: Corner Point for Continuous Edge
• Installation Position: Left
• Dimension A – Overall Length: 343 mm
• Dimension B – Cutting Edge Width: 251 mm
• Dimension C – Cutting Edge Thickness: 25 mm
• Locking Method: integrated Ultralok® locking system
