ESCO® Ultralok® U45 Clamshell Tooth – U45K (Clamshell)
Product number:
U45K
€484.04
incl. VAT €576.01
Product information
The ESCO® Ultralok® U45K is a clamshell tooth for the U45 system with the Clamshell Tooth profile and type code K. As a wear part within the Ultralok® tooth system, the point is seated with a form-fit connection in the tooth pocket at the adapter interface.
The extended point profile is intended for clamshell buckets and comparable grab applications requiring a slim cutting geometry. Point replacement is hammerless via the integrated Ultralok® locking system.
Technical Data
- System: ESCO® Ultralok®
- System Size: U45
- Part Number: U45K
- Product Type: Clamshell Tooth
- Type Code: K
- Tooth Profile: Clamshell Tooth
- Dimension A – Overall Length: 456 mm
- Dimension B – Cutting Edge Width: 102 mm
- Dimension C – Cutting Edge Thickness: 12 mm
- Dimension D – Outside Box Width: 149 mm
- Locking Method: integrated Ultralok® locking system, hammerless
| Tooth Size: | U45 |
|---|---|
| Shipping Weight: | 17.6 kg |
