LIS® Triple Grouser Track Shoe | 800 mm (32") Width | Pitch 215,90 mm | M24 holes

The LIS® Triple Grouser track shoe (Part No. CR5929NGH/800C) with a width of 800 mm is intended for use on excavators (e.g. Caterpillar 336 NGH). The triple grouser profile offers high stability and smooth operation. The 800 mm width provides a large contact area and ensures effective load distribution on the terrain. The shoe features M24 bolt holes and can be installed precisely on common link assemblies.

Important Note: Please check the bolt dimensions (here: M24) before ordering. Technical drawings are visible after registration in our shop.

Features and Benefits

• Load Capacity: 800 mm width provides a large contact area for effective load distribution.
• High Stability: The 3-bar profile minimizes vibrations and tilting for smooth operation.
• Maneuverability: The low turning resistance of the triple grouser design protects the undercarriage during frequent steering maneuvers.
• LIS® Warranty: ✓ 12 months on material/manufacturing defects*.  Learn more.

Technical Specifications

• Shoe Type: Triple Grouser
• Shoe Width: 800 mm (32")
• Pitch: 215.90 mm
• Base plate thickness: 13 mm
• Total Height: 49 mm
• Bolt Hole: M24
