LIS® Triple Grouser Track Shoe | 800 mm (32") Width | Pitch 154 mm
Product number:
KM3129/800C
€31.25
incl. VAT €37.19
Product information
The LIS® Triple Grouser track shoe (Part No. KM3129/800C) with a width of 800 mm is engineered for compact construction machinery (LGP version). The triple grouser profile offers high stability and smooth operation. The wide design provides a large contact area and ensures effective load distribution on the terrain. The shoe can be installed precisely on common link assemblies.
Important Note: Please check the bolt dimensions before ordering. Technical drawings are visible after registration in our shop.
Features and Benefits
- Load Capacity: 800 mm width provides a large contact area for effective load distribution.
- High Stability: The 3-bar profile minimizes vibrations and tilting for smooth operation.
- Maneuverability: The low turning resistance of the triple grouser design protects the undercarriage during frequent steering maneuvers.
- LIS® Warranty: ✓ 12 months on material/manufacturing defects*. Learn more.
Technical Specifications
- Shoe Type: Triple Grouser
- Shoe Width: 800 mm (32")
- Pitch: 154 mm
- Base plate thickness: 8.5 mm
- Total Height: 26.5 mm
| Shipping Weight: | 13.2 kg |
|---|
