LIS® Triple Grouser Track Shoe | 700 mm (28") Width | Pitch 190 mm

The LIS® Triple Grouser track shoe (Part No. LIS4101/700H) with a width of 700 mm is intended for use on excavators. The triple grouser profile offers high stability and smooth operation. The wide 700 mm design reduces specific ground pressure and ensures optimal load distribution on soft terrain. The shoe can be installed precisely on common link assemblies.

Important Note: Please check the bolt dimensions before ordering. Technical drawings are visible after registration in our shop.

Features and Benefits

• Load Capacity: 700 mm width provides the optimal compromise between stability and ground pressure for standard applications on mixed terrain.
• High Stability: The 3-bar profile minimizes vibrations and tilting for smooth operation.
• Maneuverability: The low turning resistance of the triple grouser design protects the undercarriage during frequent steering maneuvers.
• LIS® Warranty: ✓ 12 months on material/manufacturing defects*. Learn more.

Technical Specifications

• Shoe Type: Triple Grouser
• Shoe Width: 700 mm (28")
• Pitch: 190 mm
• Base plate thickness: 10 mm
• Total Height: 36 mm
