LIS® Double Grouser Track Shoe | 750 mm (29") Width | Pitch 260,35 mm

The LIS® Double Grouser track shoe (Part No. KM976/750C) with a width of 750 mm is engineered for large excavators in the 70-90 ton class operating in demanding terrain. The double grouser profile offers the optimal balance between high traction (for thrust and stability) and good maneuverability (turning ability) in cohesive or rocky soils. The shoe can be installed precisely on common link assemblies.

Important Note: Please check the bolt dimensions before ordering. Technical drawings are visible after registration in our shop.

Features and Benefits

• High Load Capacity: 750 mm width provides a massive contact area for large machinery, reducing sinking under heavy loads.
• Traction and Maneuverability: The profile combines high thrust for heavy-duty applications with reduced turning resistance for efficient maneuvering.
• Increased Stability: Two grousers provide significantly better stability and smoother operation than single grouser shoes.
• LIS® Warranty: ✓ 12 months on material/manufacturing defects*.  Learn more.

Technical Specifications

• Shoe Type: Double Grouser
• Shoe Width: 750 mm (29")
• Pitch: 260.35 mm
• Plate Thickness: 21 mm
