FUH100TS4BC1 Transfer and filtration portable unit
Product number:
ELS-154768
€9,809.15
incl. VAT €11,672.89
Product information
| Electrical connection: | 230/400 V; 50-60 Hz; 2.2 kW |
|---|---|
| Inlet pressure [bar]: | 15 |
| Maintenance indicator / switch: | Yes |
| Manufacturer: | FILTREC |
| Pre-filter: | Y-Filter 500µm |
| Pressure hose length [mm]: | 3000 |
| Safety valve switching pressure [bar]: | depending on the filter element |
| Suction hose length [mm]: | 3000 |
| Temperature range: | 0°C to +80°C |
| Viscosity [cSt]: | 10-800 cSt. |
| Durchfluss [l/min]: | 100 |
| Filterfeinheit [µm(c)]: | See data sheet |
| Filterelement: | Not included - suitable: U564* |
| Shipping Weight: | 0 kg |
